Driving type |
4x4 |
|
Dimension(Lx W x H) (unloaded) (mm) |
7286x2500x3250 |
|
Inner dimension (mm) |
5000x2300x600 |
|
Approaching angle/Departure angle(°) |
30/29 |
|
Overhang(front/rear) (mm) |
1410/2076 |
|
Wheel base (mm) |
3800 |
|
Max speed (km/h) |
90 |
|
Curb weight (kg) |
7910 |
|
Engine technology, made in China |
Model (WP10.290) |
WEICHAI Diesel engine, water-cooled, four strokes, 6 cylinders in line, turbocharged, directly injection |
Displacement (L) |
9.726/Diesel |
|
Bore x stroke (mm) |
126/130 |
|
Max power (kw/rpm) |
213/2200 |
|
Max torque (Nm/rpm) |
1100/1200-1600 |
|
Emission |
EURO 3 (Common rail) |
|
Clutch |
Model |
Single dry frictional disc, Hydraulic boosting |
Gearbox |
Model |
FAST 9JS135, mechanism,9gears, |
Brake system |
Service brake |
Double circulation air brake system |
Assistant brake |
Engine exhaust brake |
|
Park brake |
Potential springs pressing on middle and rear wheels |
|
Steering system |
Model |
TAS85,whole circulation in ball, hydraulic booster |
Frame |
Fish belly, shape, variable width, variable sections, side beam structure |
|
Front axle |
|
|
Middle and Rear axle |
Double-shoe pneumatic brake, casting, double reduction driving axle |
|
Tyre |
14.00-20 |
|
Electrical system |
Battery |
2X12V/135Ah |
Generator |
28V-35A |
|
Starter |
5.4Kw/24V |
|
Cab |
Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly, short cabin without sleeper |
