Tow truck(Wrecker)

Vehicle model

AUMARK-T33

Cabin

Single row/W1800/left rudder

Whole vehicle main dimensions

Overall dimensions (LxWxH)mm

5875×1915×2230

Wheel base(mm)

3360

Weight data

Curb weight(kg)

2100

Gross vehicle weight（kg）

4485

Persons in cab

3

Whole vehicle main performance

Max. speed（km/h）

95

ENGINE

Model

BJ493ZLQV1

Emissions standards

EuroⅢ

Displacement（L）

2.771

Rated Power（kw/rpm）

80

Max torque （N.m/rpm）

280

Gearbox

Model

JC5-28

Front axle

Type/Mainreducetion ratio

2.2T

Rear axle

Type/Mainreducetion ratio

5.0T/6.142

Suspension

Front suspension/Leaf spring number

3+1

Rear suspension/Leaf spring number

6+7

Brake system

Service brake

Drum pneumatic braking

Parking brake

Central drum brake

Auxiliary brake

Engine exhaust brake

Wheels and tyre size

6+1/( 7.00R16)

Superstructure Specification

Platform Organ

Dimension

4200*2320(mm)

Rear manual flip board length

1200(mm)

Material

Q235 carbon steel

Max Loading capacity

3000(kg)

Winch

Quantity

1

Winch rating towing capacity

4000(kg)

Length of steel rope

25(m)

Speed of winch

3.23~8 (m/min)

Other parts

Auxiliary wheels, alarm light, hooks, 4 bundling belt, automatic sliding plate, etc.

Options

Caution light, air condition,inlet valve.
