Flat Beds Tow Truck

Vehicle model

EST-M-4800

Drive type

LHD/RHD

Cabin

half row

Dimensions date

Wheel base(mm)

4800 , 5150

Engine

Model

YC6A240-33,ISB220 40,ISD245 50

Emissions standards

Euro 3,4,5

Rated Power（kw/rpm）

177,162,180

Horse power(hp)

240

Fuel type

Diesel

Gearbox

Model

8JS105TA,8JS118TA-B

Front axle

Loading weight

5.5.T

Rear axle

Loading weight

10T/4.875

Wheels and tyre size

6+1(11R22.5,295/80R22.5)

One-Drive-Three Flatbed Wrecker

Overview

Name

Flatbed Wrecker

Dimension(LxWxH)

8500X2470X3050(mm)

Kerb Weight

6800 Kg

Passenger

3

Approach/Departure Angle

33/22

Max. Speed

105 km/h

The Parameters of Equipment

Towing Capacity

Two Vehicles

Rated Total Capacity

12000 kg

Platform Biggest Load Bearing Quality

6000 kg

Lift Arm Capacity

6000 kg

Lift Arm Length

1300 mm

Thinkness of Plate

3-5mm

Length of Steel Line

25 m

Speed of Steel Line

10 m / min

Platform Size

5530x2300  mm

Platform Gradient

100

Platform Power Stroke

2680  mm

Common Accessories

Lift,winch,lashing hook, auxiliary wheel,bundling belt,automatic cable pulley, alarm light, wheel housing, etc.
