1,FOTON/BEIBEN/HOWO/DONGFENG/FAW chassis matchable
Key words:tow truck bed/rollback tow truck/wheel lift/rollback/towing service/freightliner/car towing/medium duty/vehicle
Vehicle model |
AUMARK-S38 |
|
Cabin |
Single row/W2060/left rudder |
|
|
Overall dimensions (LxWxH)mm |
6730×2138×2440 |
Wheel base(mm) |
3800 |
|
Weight data |
Curb weight(kg) |
3528 |
Gross vehicle weight(kg) |
11995 |
|
Persons in cab |
3 |
|
Whole vehicle main performance |
Max. speed(km/h) |
105 |
|
Model |
F3.8s3141 |
Emissions standards |
EuroⅢ |
|
Displacement(L) |
3.76 |
|
Rated Power(kw/rpm) |
105 |
|
Max torque (N.m/rpm) |
450 |
|
Gearbox |
Model |
6S558 |
Front axle |
Type/Mainreducetion ratio |
3.6T |
Rear axle |
Type/Mainreducetion ratio |
6.5T/5.286 |
Suspension |
Front suspension/Leaf spring number |
9 |
Rear suspension/Leaf spring number |
8+6 |
|
Brake system |
Service brake |
Drum pneumatic braking |
Parking brake |
Brake gas brake |
|
Auxiliary brake |
Engine exhaust brake |
|
Wheels and tyre size |
6+1/( 8.25R20 14PR) |
General Technical Parameters |
||
Superstructure |
||
Flatbed |
Dimensions |
4200x2320 (mm) |
Max. Loading Weight |
5000(kg) |
|
Operating Stroke |
2700 (mm) |
|
Min. Angle of Slope |
8(°) |
|
Platform Height from the Ground |
1070(mm) |
|
Winch |
Quantity |
1pc |
Winch Rating Pulling Capacity |
4000 (kg) |
|
Length of Steel Cable |
25 (m) |
|
Hoisting Organ |
Rating Under-Pulling Capacity |
6000 (kg) |
Rating Under-Hoisting Capacity |
2000 (kg) |
|
Fully Extended Max Under-Hoisting Capacity |
1600 (kg) |
|
Max Under-Hoist Useful Length |
1640 (mm) |
|
Remarks |
1. Equiped with One Set of Auxiliary Wheels |
