1,FOTON/BEIBEN/HOWO/DONGFENG/FAW chassis matchable
2,Water tank capacity from:3CBM-30CBM
Key words:water truck/tank truck/spraying truck/bulk water delivery/water tanker/dust control/drinking water/potable water/water supply
Vehicle model |
2634P |
|
Drive type |
LHD,RHD |
|
Cabin |
NG80B,V3 |
|
Dimensions date |
Wheel base(mm) |
3450+1450,4450+1450,5050+1450 |
Engine |
Model |
WP10.340E32,WP10.380E32 |
Emissions standards |
Euro 2 |
|
Horse power |
340hp,380hp |
|
Fuel type |
Diesel |
|
Gearbox |
Model |
9JS150A,12JS200T |
Front axle |
Loading weight |
7.5T |
Rear axle |
Loading weight |
13T*2 |
Wheels and Tyre size |
10+1(12.00R20) |
Water tank structure parameters |
|
|||
Tank dimensions |
7000X2300X1600mm |
Tank volume |
15000L |
|
Tank material |
Carbon steel |
Tank thickness |
5mm |
|
Nozzle sprinkling width |
≥14m |
Range of water cannon |
≥28m |
|
Suction height |
≥7m |
Color and Logo |
Optional |
|
Standard configuration |
Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle,rear working platform,water cannon,fire valve, water valve, filter gauze,water hose, climbing ladder. |
|||
Selective configuration |
Stainless steel/aluminum alloy water tank,insulation layer for water tank,stainless steel water pump, fire pump, fire gun,pesticide plate, cabin gas control operated, Honda pumps, lights, crane, hanging basket, rear spraying device, barrel pesticide spraying device, gasoline pesticide machine, diesel pesticide machine, LED arrow lights |
|||
Extended model |
water transporting truck, thermal insulation water transporting truck, drinking water tank truck, liquid food truck, fire water tank truck, pesticide spraying truck,and etc. |
|||
