1,FOTON/BEIBEN/HOWO/DONGFENG chassis matchable.
2, Lifitng capacity from 5T-25T
Key words:truck mounted crane with hydraulic boom/telescopic boom truck crane/hydraulic crane/truck mounted hydraulic crane/lift/pickup truck/arm crane/knuckle boom
Vehicle model |
AUMARK-S33 |
|
Cabin |
Single row/W2060/left rudder |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
5890×2105×2400 |
Wheel base(mm) |
3360 |
|
Weight data |
Curb weight(kg) |
3210 |
Gross vehicle weight(kg) |
8275 |
|
Persons in cab |
3 |
|
Whole vehicle main performance |
Max. speed(km/h) |
105 |
ENGINE |
Model |
F3.8s3141 |
Emissions standards |
EuroⅢ |
|
Displacement(L) |
3.76 |
|
Rated Power(kw/rpm) |
105 |
|
Max torque (N.m/rpm) |
450 |
|
Gearbox |
Model |
6S558 |
Front axle |
Type/Mainreducetion ratio |
3.6T |
Rear axle |
Type/Mainreducetion ratio |
6T/5.286 |
Suspension |
Front suspension/Leaf spring number |
9 |
Rear suspension/Leaf spring number |
8+6 |
|
Brake system |
Service brake |
Drum pneumatic braking |
Parking brake |
Brake gas brake |
|
Auxiliary brake |
Engine exhaust brake |
|
Wheels and tyre size |
6+1/(L8.25R1614L) |
Crane requirements |
Type/Position |
Straight arm/front |
crane |
SQ3.2SK2Q |
|
Rotation angle |
360°Full rotation |
|
Subframe |
Material/plate thickness |
Longitudinal beam :Q345/10mm Beam: Q345/8mm |
Cargo box |
size |
4170*2100*400mm |
