1,FOTON/BEIBEN/HOWO/DONGFENG chassis matchable.
2, Lifitng capacity from 5T-25T
Key words:truck mounted crane with hydraulic boom/telescopic boom truck crane/hydraulic crane/truck mounted hydraulic crane/lift/pickup truck/arm crane/knuckle boom
Vehicle model |
Auman |
|
Cabin |
AUMAN-ETX-4x2 |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
7500×2230×3250 |
Wheel base(mm) |
4500 |
|
Weight data |
Curb weight(kg) |
3980 |
Gross vehicle weight(kg) |
6495 |
|
Persons in cab |
3 |
|
Whole vehicle main performance |
Max. speed(km/h) |
95 |
ENGINE |
Model |
WP10.270E32 |
Emissions standards |
EuroⅢ |
|
Horse Power(Hp) |
270 |
|
Rated Power(kw/rpm) |
170 |
|
Gearbox |
Model |
RTD11509C,9JS119,9JSD150T-B |
Brake system |
Service brake |
Drum pneumatic braking |
Parking brake |
Central drum brake |
|
Auxiliary brake |
Engine exhaust brake |
|
Wheels and tyre size |
6+1(12.00-R20) |
