FOTON chassis preferred. Other chassis can be customerised.
Key words:freezer truck/truck refrigeration unit/Refrigerated trailers
Vehicle model |
AUMARK-E33 |
|
Cabin |
Single row/W1880/left rudder |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
5965×1960×2225 |
Wheel base(mm) |
3360 |
|
Weight data |
Curb weight(kg) |
2300 |
Gross vehicle weight(kg) |
7500 |
|
Persons in cab |
3 |
|
Whole vehicle main performance |
Max. speed(km/h) |
100 |
ENGINE |
Model |
BJ493ZLQV1 |
Emissions standards |
EuroⅢ |
|
Displacement(L) |
2.771 |
|
Rated Power(kw/rpm) |
80 |
|
Max torque (N.m/rpm) |
280 |
|
Gearbox |
Model |
5S368 |
Front axle |
Type/Mainreducetion ratio |
2.4T |
Rear axle |
Type/Mainreducetion ratio |
4.5T/5.714 |
Suspension |
Front suspension/Leaf spring number |
3 |
Rear suspension/Leaf spring number |
8+6 |
|
Brake system |
Service brake |
Drum pneumatic braking |
Parking brake |
Brake gas brake |
|
Auxiliary brake |
Engine exhaust brake |
|
Wheels and tyre size |
6+1/( 7.00R16) |
voltage |
24V |
|
|
|
Packing case |
Internal size |
4100*2000*2000 |
|
|
The material |
Inside and outside: glass steel plate, sandwich: polyurethane board (≥40kg/m3) |
|
||
thickness |
Front plate, back plate, top plate, bottom plate and left and right plate: more than 100mm |
|
||
The framework |
The upper and lower frames and front columns are aluminum profiles or stainless steel |
|
||
Open the door form |
Double rear door, passenger side single side door |
|
||
The refrigeration unit |
Brand and Specifications |
American Cold King /SV400 |
|
|
Refrigeration requirements |
Minimum temperature: -18℃ |
|
||
The optional features |
No backup electricity, no heating |
|
||
The attachment |
Protective device |
Side protection: comply with GB11567.1; Rear protection: according to GB11567.2 |
|
|
Door lock and folding |
Choose stainless steel material |
|
||
Lamps |
Adopt LED seal lamp, lampshade need to glue seal |
|
||
rear pedal |
Aluminum alloy pedal |
|
||
interior |
Equipped with patterned aluminum bottom plate and patterned anti-collision plate (300mm height) |
|
||
The special performance |
Corrosion protection |
The cargo box shall meet the salt spray test for more than 504 hours (including connecting bolts, welding points and anti-corrosion of paint surface) |
|
|
In the rain |
The rainfall intensity is 5mm ~ 7mm/min, and there is no water inflow and leakage after 30min test. |
|
||
airtight |
Under the condition that the pressure difference between inside and outside the compartment is 100± 10Pa, the air leakage ratio is less than or equal to 6.3L /h |
|
||
Heat insulation |
The average wall temperature of the carriage is 293K ~ 298K, and the total heat transfer coefficient K is less than or equal to 0.5 |
|
Technical parameters of refrigerated truck
