1,FOTON/BEIBEN/HOWO/DONGFENG/FAW chassis matchable
Key words:firefighter/engine/fire department/rescue vehicle/forest fire/fire station/fire engines/fire apparatus/brush truck
Vehicle model |
AUMARK-T33 |
|
Cabin |
Single row/W1800/left rudder |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
5875×1915×2230 |
Wheel base(mm) |
3360 |
|
Weight data |
Curb weight(kg) |
2100 |
Gross vehicle weight(kg) |
4485 |
|
Persons in cab |
3 |
|
Whole vehicle main performance |
Max. speed(km/h) |
95 |
ENGINE |
Model |
BJ493ZLQV1 |
Emissions standards |
EuroⅢ |
|
Displacement(L) |
2.771 |
|
Rated Power(kw/rpm) |
80 |
|
Max torque (N.m/rpm) |
280 |
|
Gearbox |
Model |
JC5-28 |
Front axle |
Type/Mainreducetion ratio |
2.2T |
Rear axle |
Type/Mainreducetion ratio |
5.0T/6.142 |
Suspension |
Front suspension/Leaf spring number |
3+1 |
Rear suspension/Leaf spring number |
6+7 |
|
Brake system |
Service brake |
Drum pneumatic braking |
Parking brake |
Central drum brake |
|
Auxiliary brake |
Engine exhaust brake |
|
Wheels and tyre size |
6+1/( 7.00R16) |
Water tank |
|
Capacity |
3000 liters |
Material |
Carbon steel |
Water pump |
|
Model |
CB20 |
Flow |
20L/S |
Pressure |
1.0Mpa |
MaximumSuction depth |
7 meters |
Water intake time when the maximum suction depth |
£50S |
Monitor |
|
Model |
PS20 |
Swing angle |
360° horizontal rotation |
Range |
water ³40 m |
Flow |
24L/S |
Size |
|
Size of truck |
Appro 6970×2330×2550 |
Total weight |
9500kg |
Curb weight |
3800kg |
Work weight |
6000kg |
