1,All brands chassis matchable.
2,Drum Volume from 6CBM-18CBM.
Key words:truck mixer/transit mixer machine/cement mixer truck
Vehicle model |
CAM5310GJB |
|
Chassis |
AUMAN-8X4 |
|
Drive type |
LHD |
|
Cabin |
half row |
|
Dimensions date |
Wheel base(mm) |
1800+4700+1350 |
Engine |
Model |
WP10.340E32,ISGe4-330 |
Emissions standards |
Euro 3 ,4 ,5 |
|
Rated Power(kw/rpm) |
250,243 |
|
Horse power(hp) |
340,330 |
|
Fuel type |
Diesel |
|
Gearbox |
Model |
12JSD160TA,10JSD180T |
Front axle |
Loading weight |
7.5T*2 |
Rear axle |
Loading weight |
13T*2 |
Wheels and tyre size |
12+1(12.00-R20) |
Mixer specification |
||||
Mixer
|
Tanker material |
16MnQ345 |
||
Mix Capacity(m³) |
12-16 |
Reducer |
PMB6.5 |
|
Charge Speed(m³/min) |
≥2.8 |
Hydraulic Pump |
PMH P90 |
|
Discharge Speed(m³/min) |
≥1.2 |
Hydraulic Motor |
PMH M90 |
|
Residual rate(%) |
≤0.5 |
Radiator |
Changzhou KAITONG |
|
Mixing speed |
0-18 |
Length of Discharge slot(mm) |
1800 |
|
Water supply system |
Water capacity(L) |
400 |
||
|
Water Supplying Method |
Pressure |
||
Operation Method |
Shaft operation |
|||
Structure Features |
1, Mixing drum and leaf with special wear-resistant materials; |
|||
|
2, Discharge trough, into the hopper and cylinder liner use the same wear-resistant materials used; |
|||
|
3, Control system user-friendly, flexible shaft operation, simple and safe and reliable; |
|||
|
4, Use famous brand hydraulic system; |
|||
|
Washing system operated in the back,discharge fast , no surplus |
|||
Option |
hydraulic sytem made in China |
