1,FOTON/BEIBEN/HOWO/DONGFENG chassis matchable
Key words:garbage compactor truck/garbage truck/recycling/rear load/garbage collection/solid waste cargo truck
Vehicle model |
CSM5150YS |
|
Drive type |
LHD/RHD |
|
Cabin |
AUMAN-ETX |
|
Dimensions date |
Wheel base(mm) |
4500 |
Engine |
Model |
WP10.270E32 |
Emissions standards |
Euro 3 ,4 ,5 |
|
Rated Power(kw/rpm) |
198 |
|
Horse power(hp) |
270 |
|
Fuel type |
Diesel |
|
Gearbox |
Model |
RTD11509C,9JS119,9JSD150T-B |
Front axle |
Loading weight |
7.5T |
Rear axle |
Loading weight |
13T |
Wheels and tyre size |
6+1(12.00-R20) |
Technical Parameters |
Effective volume of garbage body |
10-14m³ |
Filler volume |
≥0.6m³ |
|
garbage body type |
Arc-shaped |
|
garbage body material |
T420/Q355/Q235 Thickness of side plate: 4mm Thickness of bottom plate: 4mm |
|
Rated pressure of hydraulic system |
≤18(Mpa) |
|
Loading garbage time |
≤25s |
|
Discharging garbage time |
≤45s |
|
Filler lifting time |
≤12s |
|
Compression ratio |
≥2.5 |
|
Wastewater tank |
2 units |
|
Back flip form |
Hang dust bin (120L /240L /660L) |
|
Optional: Dustpan hopper, fulling sealing,swing arm hopper. |
||
Hydraulic system |
Cylinder |
9 pieces, China famous brand |
Oil pump |
China famous brand |
|
Multi-way valve |
China famous brand |
|
Hydraulic tank |
1 piece |
|
Hydraulic tubing |
Black rubber steel wire hose and steel oil pipe |
|
Control system |
Manual control |
Manual operation device |
Electronic control |
CAN system, 1 set in the cab |
|
CAN system, 1 set on the filler |
||
With Emergency off switch |
||
Process requirements |
Corrosion inside the tank |
Industrial grade anti-corrosion |
Glue requirements |
The tank body, mudguard, sub-frame welded joints and side lights need to be treated with sealant |
