1,FOTON/BEIBEN/HOWO/DONGFENG chassis matchable
Key words:garbage compactor truck/garbage truck/recycling/rear load/garbage collection/solid waste cargo truck
Cabin |
Left rudder/half row |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
8255×2460×2820 |
Wheel base(mm) |
4800 |
|
Weight data |
Curb weight(kg) |
5440 |
Gross vehicle weight(kg) |
22000 |
|
Persons in cab (persons) |
2 |
|
Engine |
Model |
YC6A240-33 |
Emissions standards |
Euro III |
|
Displacement(L) |
7.255L |
|
Rated Power |
177 |
|
Max torque |
900 |
|
Gearbox |
Model |
8JS105TA |
Clutch |
Type |
Single dry diaphragm spring |
Front axle |
Type |
5.5.T |
Rear axle |
Type/Main reducetion ratio |
10T/4.875 |
Suspension |
Front suspension/Leaf spring number |
Non-independent suspension longitudinal plate spring /10 |
Rear suspension/Leaf spring number |
Non-independent suspension longitudinal plate spring /10+8 |
|
Brake system |
Service brake |
Drum-type pneumatic brake |
Parking brake |
Barely able to brake |
|
Basic equipment |
Hydraulic Turnover/Cruise + 135A.H Battery/Manual Air Conditioners/Tuberless Tire (Inch) 11R22.5/ Manual Doors, Windows and Rearview Mirrors /MP3 / Power Steering/Knit Shock Absorber Seat (Spring) |
