Trash can Garbage Compactor Mobile Station

ITEM

UNIT

DATA

Truck model

/

MTC20-B

Compression way

/

Horizontal compression

Overall dimension(will design to put into the 40HQ)

mm

7000*2280*2550 (L*W*H)

Theoretical waste treatment capacity

Ton/ Hour

20

Motor power

KW

7.5

Maximum system pressure

MPa

≥21, pump or Mazu gear pump imported from Italy

Maximum compression force

KN

360

Maximum lifting force of loading mechanism

TON

/

Garbage container volume

m³

20

Compression chamber volume

m³

3.5

Head stroke volume

Ton/m³

≥1.5

Compaction density

S

≥0.75

No-load compression cycle time

S

≤60

Cycle time of feeding mechanism

mm

≤20

Guide rail width

mm

/

Door opening method after unloading

/

Quick-change hydraulic joint

Lifting arm height

mm

1370+_10

Power Supply

/

415 volts 3phase 50-60hz, waterproof design

Optional garbage bucket volume

/

It is suitable to lift 240L, 660L, 770L, 1100L garbage bin
