1,FOTON/BEIBEN/HOWO/DONGFENG/FAW chassis matchable
Key words:tow truck/rotator wrecker/miller industries/die cast/vulcan/twin steer/vehicles/metro tow
Vehicle model |
3138KZ |
|
Drive type |
LHD,RHD |
|
Cabin |
NG80B,V3 |
|
Dimensions date |
Wheel base(mm) |
1500+5050+1450 |
Engine |
Model |
WP10.380E32,WP10.420E32 |
Emissions standards |
Euro 2 |
|
Horse power |
380hp,420hp |
|
Fuel type |
Diesel |
|
Gearbox |
Model |
12JS200T |
Front axle |
Loading weight |
7.5T*2 |
Rear axle |
Loading weight |
13T*2 |
Wheels and Tyre size |
12+1(12.00R20) |
RECKER EQUIPMENT |
||
Max. Towing Weight(kg) |
43000 |
|
Lifting System |
Max. Lifting Weight(kg) |
25000 |
Max. Lifting Weight under all extension(kg) |
8300 |
|
Effective Length of Corbeling Arm(mm) |
3650 |
|
Extend-retract of Corbeling Arm(mm) |
1750 |
|
Slope Angle of Corbeling Arm(°) |
7 |
|
Folding angle under no load(°) |
-7~92 |
|
Folding angle under load(°) |
-7~16 |
|
Max. Ground Distance(mm) |
≮900 |
|
Landing Strength(KN) |
80*2 |
|
Hydraulic Hose |
Tianhe,Guangdong Province |
|
Hydraulic Joint |
Germany technology and exported Sealing rings |
|
Hydraulic Lock |
Jiangyin Mingcheng Hydraulic and Mechanical Co.,Ltd. |
|
Swivel Joint |
Yangzhou Zhongmei Pressure Parts Co.,Ltd. |
|
Compartment plate |
One-step Modeling by Germany 3P2A 1000T punching machine |
