Mobile Food Truck

Vehicle model

TM-R

TM-L

Drive type

RHD

LHD

Cabin

Single row

Single row

Dimensions date

Wheel base(mm)

2400

2850 , 3070

Engine

Model

QC480Q

DAM15L,QC485,DAM15L,DAM-1.5,LJ469

Emissions standards

Euro 1

Euro 1,2,4,5

Rated Power（kw/rpm）

29

65,82

Horse power(hp)

40

88,112

Fuel type

Diesel

Diesel,Petrol

Gearbox

Model

MG70

DAT18R,5T20,T15R,MR513B

Front axle

Loading weight

1.2T

1.5T

Rear axle

Loading weight

2.3T/5.375

1.3T,15.T,2.5T

Wheels and tyre size

4+1/(175R14)

4+1,6+1,/(175R14,185R14)

Box

Referred Dimensions(mm)

4450*1900*1940

Logo and colour

Customized by customer's requirements

Exterior material

Color steel plate

Interior side plate material

Fiberglass

Interior bottom material

Fiberglass

Standard Configuration

Both sides turn up with bar,rear turn up, the truck is equipped with power

Amplifier horn and external power plug,non-skid aluminum decorative pattern bottom plate, lighting can be optional to install ceiling lamp or layout LED light strip.

EQUIPMENT FOR OPTION

Doughnut machine

Popcorn machine

Grills

Griddles

Smoke extractor

Microwave oven(Big/Small)

Snacks display window,

Work bench

Double fryer

Exhaust hood

Upgrade fridge(Big/Small)

Air conditioner

Alternator

Hand sink

Waterproof sticker (Free)

Laser body advertisement

Waterproof sticker (Free)

Laser body advertisement
