Standard |
GB4732-1995 Steel pressure vessels |
|
GB/T19905-2005 Liquefied gas truck |
||
Pressure vessel safety technology and inspection procedures |
||
Liquefied gas tanker safety monitoring procedures |
||
Tanker Essential |
Dimensions(length*width*height) |
13000×2500×3990(MM) |
Estimated Tare Weight |
15600KG |
|
Payload |
24400KG |
|
Total Weight |
40000KG |
|
Shell Of Tanker |
Products |
LPG, Butane , Propane |
Fluidproperty |
flammable |
|
Design temperature |
50°C |
|
Design pressure |
1.61MPa |
|
Corrosion allowance |
1.0mm |
|
Major materials of bearing pressure |
Tanker body : Q370R |
|
End plate : Q370R |
||
Main Beam : Q345B |
||
Compartments |
One |
|
Baffle inside the tank |
14-off Aluminium bolted plate ,thickness is 5mm |
|
Shape |
Cylindrical ; Ellipse head |
|
Safety Valve |
Quantity |
Two |
Location |
On the top of tanker ; |
|
Type |
Only weld suitable flange |
|
Size |
As customer's requirement |
|
Running System |
Axles |
13 TON BPW Axles |
Suspension system |
Mechanical suspension |
|
Wheel rim |
9.0-22.5 |
|
Tyre |
12R22.5 |
|
Kingpin |
JOST2",bolt on ,in rubbing plate |
|
Landing legs |
JOST |
|
Pneumatic Braking System |
WABCO RE 6 relay valve; Spring brake chamber; 2 pieces of 45L air tanks |
|
Electronical System |
7-Pin Socket |
24V 7-pin socket |
LED Lamp |
All kinds of lamp |
|
Cable |
Stander cable |
