Chassis model |
BJ5043V9 |
Chassis brand |
FORLAND |
||
|
Overall dimensions |
5900x1960x2190mm |
Wheel base |
3360mm |
||
|
Front/rear wheel track |
1415/1485mm |
Front/rear suspension |
1085/1430mm |
||
|
Approach/departure angle |
23/19° |
Maximum speed |
95km/h |
||
|
Chassis Manufacturer |
Beiqi foton motor Co., Ltd. |
||||
|
Cab |
Configuration |
D1695, Single row |
|||
|
Color |
white,other color is optional |
||||
|
Engine |
Model |
N490 |
|||
|
Emission |
Euro 1 |
||||
|
Type |
4 cylinders,in-line,4-stroke,turbo inter-cooling,diesel engine |
||||
|
Rated power |
75hp,rated power speed 3200rpm |
||||
|
Displacement |
2544ml |
||||
|
Max.torque |
210N·m |
||||
|
Manufacturer |
Quanchai Engine power Co., Ltd. |
||||
|
Tire |
Size |
6.50-16 |
|||
|
Number |
6+1 nos |
||||
|
Rear axle |
4000kg |
Drive form |
4X2 |
||
|
Rated voltage |
24V,DC |
Steering wheel |
Left hand drive |
||
|
Transmissions |
5 speed forward 1 reverse. |
||||
|
If there is a slight change in the chassis parameters above,please take the actual product as the standard |
|||||
Up-parts Description |
|
|||||
Asphalt tank Outline Dimension (mm) |
2730x1950x1300 |
|
||||
Asphalt tank Inner Dimension(mm) |
2630x1850x1200 |
|
||||
Insulating layer thickness (mm) |
50 |
|
||||
Asphalt tank Total Volume(L) |
4000 |
|
||||
Hydraulic pump |
CBQ550-L |
|
||||
Proportional valve |
Taiwan EFBG-03-160-HF |
|
||||
Asphalt pump |
QGB680 |
|
||||
Hydraulic motor for asphalt pump |
05-110-BD31 |
|
||||
Heating System |
Italian burner Riello |
|
||||
Heat-transfer oil pump |
25-25-160 |
|
||||
Control System |
SIEMENS CLW-39-01 |
|
||||
Generator |
5.5KW gasoline engine generator |
|
||||
Number of nozzle |
30-39 |
|
||||
Spray medium |
Hot asphalt/ Hot modified asphalt/ Cutback asphalt/ Emulsified asphalt |
|
||||
Spray width(m) |
4.5-6 |
|
||||
Spray amount(L/m2) |
0.2-2 |
|
||||
Working Condition: |
1,Altitude: 0-4500m |
|
||||
