Ambulance-Transfer Type-G9

　Transfer type

G9

Left and right rudder

right rudder

Fuel type

Diesel oil

Cabin

Wide body, high ceiling

Whole vehicle main dimensions

Overall dimensions (LxWxH)mm

5380×1920×2285

Wheel base(mm)

3110

Weight data

Curb weight(kg)

2060

Gross vehicle weight（kg）

3400

Persons in cab         (persons)

2

Whole vehicle main performance

Max. speed（km/h）

≥145

Engine

Model

ISF2.8s4129P

Emissions standards

EuroⅣ

Displacement（ML）

2780

Rated Power（kw/rpm）

96

Max torque

280

Gearbox

Model

唐齿038J2

Brake system

Service brake

Disc/Drum

Parking brake

Wheel side brake

Project name

Quantity

unit

100W Long row of lights and sirens (LED all blue)

1

set

Snail light

2

each

Central partition (with sliding window)

1

set

PVC medical floor

1

each

Front medicine cabinet (with medical staff seat)

1

set

Stainless steel dirt bucket

1

each

10L Oxygen cylinder and bracket (including accessories)

1

set

Aluminum alloy stretcher (including fixing device)

1

set

Long seat (with seat belt)

1

each

UV disinfection lamp

1

each

LEDIndoor lights

1

each

Sliding bottle rack

1

each

ventilator

1

each

2 kg fire extinguisher and bracket

1

set

Appearance logo (reflective strip, star of life, red cross)

1

set

Matte film

1

set
